Important notes
Protection of persons
5.1
5.1.1

5.1−1
EDSVF9383V EN 7.1−04/2012
5.1 Important notes
 Stop!
The drive controller contains electrostatically sensitive
components.
The personnel must be free of electrostatic charge when carrying
out assembly and service operations.
5.1.1 Protection of persons
 Danger!
Before working on the controller, check that no voltage is applied
to the power terminals:
Æ’ The power terminals U, V, W, +U
G
, −U
G
, BR1, BR2 and
101 ... 104 remain live for at least five minutes after
disconnecting the mains.
Æ’ The power terminals L1, L2, L3, U, V, W, +U
G
, −U
G
, BR1, BR2 and
101 ... 104 remain live when the motor is stopped.
All pluggable terminals must only be connected or disconnected when no
voltage is applied!
Pluggable terminal strips
