Configuration
Selection lists
Selection list 2: Digital output signals
8
8.6
8.6.2

8.6−3
EDSVF9383V EN 7.1−04/2012
8.6.2 Selection list 2: Digital output signals
Parameter Digital output signal (,)
000051 DIGIN1
000052 DIGIN2
000053 DIGIN3
000054 DIGIN4
000055 DIGIN5
000056 DIGIN6(ST)
000065 DIGIN−CINH
000100 DFSET−ACK
000500 DCTRL−RDY
000501 DCTRL−CINH
000502 DCTRL−INIT
000503 DCTRL−IMP
000504 DCTRL−NACT=0
000505 DCTRL−CW/CCW
001000 FIXED0
001001 FIXED1
002000 DCTRL−PAR*1
002001 DCTRL−PAR*2
002002 DCTRL−PAR−BUSY
005001 MCTRL−QSP−OUT
005002 MCTRL−IMAX
005003 MCTRL−MMAX
005006 MCTRL−GSB−OUT
005050 NSET−RFG−I=0
006000 DFRFG1−FAIL
006001 DFRFG1−SYNC
006100 MFAIL−STATUS
006101 MFAIL−I−RESET
006400 FCNT1−EQUAL
010000 BRK1−OUT
010001 BRK1−CINH
010002 BRK1−QSP
010003 BRK1−M−STORE
010250 R/L/Q−QSP
010251 R/L/Q−R/L
010500 AND1−OUT
010505 AND2−OUT
010510 AND3−OUT
010515 AND4−OUT
Parameter Digital output signal (,)
010520 AND5−OUT
010550 OR1−OUT
010555 OR2−OUT
010560 OR3−OUT
010565 OR4−OUT
010570 OR5−OUT
010600 NOT1−OUT
010605 NOT2−OUT
010610 NOT3−OUT
010615 NOT4−OUT
010620 NOT5−OUT
010650 CMP1−OUT
010655 CMP2−OUT
010660 CMP3−OUT
010665 CMP4−OUT
010700 DIGDEL1−OUT
010705 DIGDEL2−OUT
010750 TRANS1−OUT
010755 TRANS2−OUT
010900 FLIP1−OUT
010905 FLIP2−OUT
011000 DCALC1−DMAX
011001 DCALC1−DMIN
011002 DCALC1−I=0
011003 DCALC1−OVFL
011100 INT1−DOUT
011105 INT2−DOUT
013000 FEVAN1−BUSY
013001 FEVAN1−FAIL
015000 DCTRL−TRIP
015001 DCTRL−MESS
015002 DCTRL−WARN
015003 DCTRL−FAIL
015010 MONIT−LU
015011 MONIT−OU
015012 MONIT−EEr
015013 MONIT−OC1
015014 MONIT−OC2
015015 MONIT−LP1
015016 MONIT−OH
015017 MONIT−OH3
