8.3.9 DC−bus voltage
In C0173 the mains voltage and DC−bus voltage are set. From this the
switching thresholds for overvoltage and undervoltage result.
EVF9335 ... EVF9338
EVF9381 ... EVF9383
Selection
Mains
voltage
Operation
with brake
transistor
Message LU
(undervoltage)
Message OU
(overvoltage)
C0173 set reset set reset
[V AC] [V DC] [V DC] [V DC] [V DC]
ExV210
ExV240
ExV270
ExV300
0
< 400 yes / no 285 430 770 755
1 400
yes / no
285 430 770 755
2 460 yes / no 328 473 770 755
3 480 no 342 487 770 755
4 480 yes 342 487 800 785
5 500 yes / no 342 487 900 885
Ex
ExV060
ExV110
read
only
400 yes / no 285 430 700 685
C0173 = 1: Lenze setting
If the DC−bus voltage exceeds the upper switch−off threshold set in C0173,
warning OU is activated.
If the DC−bus voltage falls below the lower switch−off threshold set in C0173,
the LU message is triggered.
Æ’ An undervoltage message > 3 seconds is interpreted as an operating
state (e.g. mains switched off) and entered in the history buffer. The
entry is, however, deleted as soon as the cause has been eliminated
(e.g. mains switched on again).
This operating state can occur if the control module is already supplied
externally via terminals X5/39 and X5/59, but the mains voltage is not yet
switched on.
Æ’ An undervoltage message < 3 seconds is interpreted as a fault
(e.g.mains fault), entered in the history buffer and saved.
8.3.10 External error (EEr)
A HIGH signal at DCTRL−TRIP−SET triggers the EEr fault.
You can, for example, connect the digital input DCTRL−TRIP−SET with an
input terminal (X5/Ex). In this way an external encoder can trigger the EEr
fault.
The response can be set under C0581.
