Parameter setting
Parameter setting with the XT EMZ9371BC keypad
Loading a parameter set
7
7.2
7.2.5

7.2−6
EDSVF9383V EN 7.1−04/2012
7.2.5 Loading a parameter set
The keypad serves to load a saved parameter set into the main memory
when the controller is inhibited. After the controller is enabled, it operates
with the new parameters.
 Danger!
Æ’ When a new parameter set is loaded, the controller is
reinitialised and acts as if it had been connected to the mains:
– System configurations and terminal assignments can be
changed. Make sure that your wiring and drive configuration
comply with the settings of the parameter set.
Æ’ Only use terminal X5/28 as source for the controller inhibit!
Otherwise the drive may start in an uncontrolled way when
switching over to another parameter set.
 Note!
Æ’ After switching on the supply voltage, the controller always
loads parameter set 1 into the main memory.
Æ’ It is also possible to load other parameter sets into the main
memory via the digital inputs or bus commands.
Step Key
sequence
Action
1. Inhibit controller Terminal X5/28 = LOW
2.
Load the saved parameter set
into the main memory
A  )  * Select the code C0002 "PAR LOAD" in the
menu "Load/Store"
B  Change to the parameter level
The active parameter set is displayed, e. g.
display "0" and "Load Default"
If you want to restore the delivery status,
proceed with D
Select the parameter set
to be loaded
C 
Load parameter set 1:
ð Set "1" "Load PS1"
Load parameter set 2:
ð Set "2" "Load PS2"
Load parameter set 3:
ð Set "3" "Load PS3"
Load parameter set 4:
ð Set "4" "Load PS4"
D (  "RDY" goes off. The parameter set is loaded
completely into the main memory if "RDY"
is displayed again.
3.
Change to the code level
A  Display of the operating level
B  Display of C0002 "PAR LOAD"
4. Enable controller Terminal X5/28 = HIGH
The drive is running with the settings of
the loaded parameter set
