Lenze EVS9321-Ex System Manual

Basic devices in the power range 250 ... 400 kW
Fuses and cable cross−sections
5.5
5.5.7

5.5−10
EDSVF9383V EN 7.1−04/2012
5.5.7 Fuses and cable cross−sections
Supply conditions
Range Description
Fuses l Utilisation category: only gG/gL or gRL
Cables Laying systems B2 and C: Use of PVC−insulated copper cables, conductor
temperature < 70 °C, ambient temperature < 40 °C, no bundling of the cables or
cores, three loaded cores. The data are recommendations. Other
dimensionings/laying systems are possible (e.g. in accordance with VDE 0298−4).
RCCB l Controllers can cause a DC current in the PE conductor. If a residual current
device (RCD) or a fault current monitoring unit (RCM) is used for protection in
the case of direct or indirect contact, only one RCD/RCM of the following type
can be used on the current supply side:
– Type B (universal−current sensitive) for connection to a three−phase system
– Type A (pulse−current sensitive) or type B (universal−current sensitive) for
connection to a 1−phase system
Alternatively another protective measure can be used, like for instance
isolation from the environment by means of double or reinforced insulation,
or isolation from the supply system by using a transformer.
l Earth−leakage circuit breakers must only be installed between mains supply
and controller.
Observe all national and regional regulations!
9300 Fuse Cable cross−section FI
1)
Rated fuse current Laying system F
L1, L2, L3 PE
Type [A] [mm
2
] [mm
2
] [mA]
EVF9381−EV
EVF9381−EVVxxx
Slave 315
150
2 × 50
1)
95 300
EVF9382−EV
EVF9382−EVVxxx
Master 315
150
2 × 50
1)
95 300
Slave 315
150
2 × 50
1)
95 300
EVF9383−EV
EVF9383−EVVxxx
Master 400
240
2 × 95
1)
150 300
Slave 400
240
2 × 95
1)
150 300
1)
Two conductors per path; both conductors must have the same cross−section
2)
Universal current−sensitive earth−leakage circuit breaker
9300 Fuse Cable cross−section
Quantity Rated fuse current Laying system F
+U
G
, −U
G
PE
Type [A] [mm
2
] [mm
2
]
EVF9381−EVV2xx
EVF9381−EVV300
Master 1
400 2 × 50
1)
95
Slave 1 400 2 × 50
1)
95
EVF9382−EVV2xx
EVF9382−EVV300
Master 2 350 2 × 95
1)
95
Slave 2 350 2 × 95
1)
95
EVF9383−EVV2xx
EVF9383−EVV300
Master 2 400 2 × 95
1)
150
Slave 2 400 2 × 95
1)
150
1)
Two conductors per path; both conductors must have the same cross−section
Installation in accordance
with EN 60204−1
Fuses and cable cross−sections
for the mains connection
Fuses and cable cross−sections
for DC−bus connection
