6.5 Changing the assignment of the control terminals X5 and X6
 Danger!
If you select a configuration in C0005, the signal assignment of
the inputs and outputs will be overwritten with the
corresponding basic assignment!
Æ’ Adapt the signal assignment to your wiring!
6.5.1 Free configuration of digital input signals
Æ’ Internal digital signals can be freely linked with external digital signal
sources. This serves to establish a freely configurable control of the
drive controller.
– Digital inputs X5/E1 ... X5/E5
Æ’ A signal source can be linked with several targets. Ensure reasonable
linkages for not activating functions that are mutually exclusive (e. g.
linking a digital input with quick stop and DC injection braking at the
same time).
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0114
0 High active HIGH level is
active
Inversion of digital input signals at
X5, function block DIGIN

6.5−1
See System
Manual
(extension)
1 LOW active LOW level is active
1 DIGIN1 pol 0 Terminal X5/E1
2 DIGIN2 pol 0 Terminal X5/E2
3 DIGIN3 pol 0 Terminal X5/E3
4 DIGIN4 pol 1 Terminal X5/E4
5 DIGIN5 pol 0 Terminal X5/E5
5 DIGIN6 (ST) pol 0 Terminal X5/ST
