Changing the assignment of the control terminals X5 and X6
Free configuration of digital outputs
6.5
6.5.2
6.5−3
EDSVF9383V EN 7.1−04/2012
6.5.2 Free configuration of digital outputs
ƒ The digital outputs X5/A1 ... X5/A4 can be freely linked with internal
digital signals.
ƒ One signal source can be linked with several targets.
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0117
Selection list 2 Configuration of digital inputs
signals, function block DIGOUT
A change of the basic
configuration in C0005 changes
the signal assignment!
6.5−3
See System
Manual
(extension)
1 CFG: DIGOUT1 15000 DCTRL−TRIP Terminal X5/A1
2 CFG: DIGOUT2 10650 CMP1−OUT Terminal X5/A2
3 CFG: DIGOUT3 500 DCTRL−RDY Terminal X5/A3
4 CFG: DIGOUT4 5003 MCTRL−MMAX Terminal X5/A4
C0118
0 High active HIGH level is
active
Inversion of digital output signals,
function block DIGOUT
1 LOW active LOW level is active
1 DIGOUT1 pol 1 Terminal X5/A1
2 DIGOUT2 pol 1 Terminal X5/A2
3 DIGOUT3 pol 0 Terminal X5/A3
4 DIGOUT4 pol 0 Terminal X5/A4
The digital outputs can be linked with internal digital signals by entering the
selection figure of the internal signal into corresponding subcode of C0117.
Example
ƒ C0117/2 = 505 ð signal source for X5/A2 is the status message
"direction of rotation" (DCTRL−CW/CCW)
ƒ Terminals (X5/A1 ... X5/A4):
– HIGH = +12 V ... +30 V
– LOW = 0 V ... +3 V
ƒ Response times: 1 ms
In C0118 you can define the active signal level (HIGH level active or LOW level
active) for the terminals X5/A1 ... X5/A4.
Example
ƒ C0118/2 =1 ð With LOW level at X5/A2 the motor rotates in CW
direction (with in−phase motor connection)
Description
Linking signals
Signal level
Inverting the signal level
