7.2.6 Transferring parameters to other standard devices
Parameter settings can be easily copied from one standard device to another
by using the keypad.
For this purpose use the "Load/Store" menu
 Danger!
During the parameter transfer from the keypad to the standard
device the control terminals can adopt undefined states!
Therefore the plugs X5 and X6 must be disconnected from the
standard device before the transfer takes place. This ensures that
the controller is inhibited and all control terminals have the
defined state "LOW".
 Note!
After copying the parameter sets into the XT keypad
(C0003 = 11), always the parameter set that was loaded last via
C0002 is activated.
Like this the current parameters also remain active after copying:
Æ’ Save the current parameters in the parameter set before
copying and load this parameter set in the controller via
C0002.
Step Key
sequence
Action
1. Connect the keypad to
standard device 1
2. Inhibit controller Terminal X5/28 = LOW
The drive coasts.
3. Select C0003 in the
"Load/Store" menu
)*
Select code C0003 "PAR SAVE" in the
"Load/Store" menu using the arrow keys.
4. Change to the parameter level

Display "0" and "READY"
5. Copy all parameter set into the
keypad
The settings saved in the keypad are
overwritten.

Set "11" "Save extern"
6. Start copying
(
The "RDY" status display goes off. As
parameter value "BUSY" is displayed.
If "BUSY" goes off after approx. one
minute, all parameter sets were copied into
the keypad. The "RDY" status display is lit.
7.
Change to the code level
A

Display of the operating level
B

Display C0003 and "PAR SAVE"
8. Enable controller Terminal X5/28 = HIGH
9. Remove keypad from standard
device 1
Copying parameter sets from
the standard device into the
keypad
