Braking operation
Rated data of the integrated brake transistor
12
12.3

12.3−1
EDSVF9383V EN 7.1−04/2012
12.3 Rated data of the integrated brake transistor
Rated data for types EVF93xx−EVV060 and EVF93xx−EVV110 at 400 V rated mains voltage
Brake transistor
9300 vector
EVF9335−EVV060
EVF9335−EVV110
EVF9336−EVV060
EVF9336−EVV110
EVF9337−EVV060
EVF9337−EVV110
EVF9338−EVV060
EVF9338−EVV110
Threshold V
DC
[V DC] 685
Peak brake current [A DC] 315 375 450 560
Max. continuous
current
[A DC] 210 250 300 375
Lowest permissible
brake resistance
1)
[W] 2.2 1.8 1.5 1.2
Current derating Derate the peak brake current by 2.5 %/°C above 40 °C
Derate the peak brake current by 5 %/1000 m above 1000 m a.m.s.l.
Switch−on cycle
3)
max. 60 s braking at peak brake power, followed by min. 30 s break
Brake transistor
9300 vector
EVF9381−EVV060
2)
EVF9381−EVV110
2)
EVF9382−EVV060
2)
EVF9382−EVV110
2)
EVF9383−EVV060
2)
EVF9383−EVV110
2)
Threshold V
DC
[V DC] 685
Peak brake current [A DC] 2 × 375 2 × 450 2 × 560
Max. continuous
current
[A DC] 2 × 250 2 × 300 2 × 375
Lowest permissible
brake resistance
1)
[W] 1.8 1.5 1.2
Current derating Derate the peak brake current by 2.5 %/°C above 40 °C
Derate the peak brake current by 5 %/1000 m above 1000 m a.m.s.l.
Switch−on cycle
3)
max. 60 s braking at peak brake power, followed by min. 30 s break
1)
Please consider the cable resistance if you use longer connection cables. The cable resistance must
be added to the brake resistance and has therefore a considerable influence on the total
resistance.
2)
Device consists of master and slave connected in parallel. Usually, the brake energy is dissipated
evenly via master and slave.
3)
Please see the switch−on cycle of the brake resistor used.
