Configuration
Selection lists
Selection list 10: Error messages
8
8.6
8.6.6

8.6−8
EDSVF9383V EN 7.1−04/2012
8.6.6
Selection list 10: Error messages
Parameter
Error message
000000
No fail
000011
OC1 TRIP
000012
OC2 TRIP
000013
OC3 TRIP
000015
OC5 TRIP
000016
OC6 TRIP
000018
OC8 TRIP
000032
LP1 TRIP
000050
OH TRIP
000053
OH3 TRIP
000057
OH7 TRIP
000058
OH8 TRIP
000061
CE0 TRIP
000062
CE1 TRIP
000063
CE2 TRIP
000064
CE3 TRIP
000065
CE4 TRIP
000070
U15 TRIP
000071
CCr TRIP
000072
PR1 TRIP
000073
PR2 TRIP
000074
PEr TRIP
000075
PR0 TRIP
000077
PR3 TRIP
000078
PR4 TRIP
000079
PI TRIP
000083
Sd3 TRIP
Parameter
Error message
000085
Sd5 TRIP
000086
Sd6 TRIP
000091
EEr TRIP
000105
H05 TRIP
000107
H07 TRIP
000110
H10 TRIP
000111
H11 TRIP
000140
Id1 TRIP
000141
Id2 TRIP
000200
NMAX TRIP
001030
LU Message
001091
EEr Message
002018
OC8 Warning
002020
OU Warning
002032
LP1 Warning
002053
OH3 Warning
002054
OH4 Warning
002057
OH7 Warning
002058
OH8 Warning
002061
CE0 Warning
002062
CE1 Warning
002063
CE2 Warning
002064
CE3 Warning
002065
CE4 Warning
002083
Sd3 Warning
002085
Sd5 Warning
002086
Sd6 Warning
002091
EER Warning
