Troubleshooting and fault elimination
System error messages
General error messages
9
9.5
9.5.1

9.5−1
EDSVF9383V EN 7.1−04/2012
9.5 System error messages
9.5.1 General error messages
 Note!
In the case of a query via system bus (CAN), the fault messages
are represented as numbers (see first column of the table).
Fault message
Description Cause Remedy
No. Display
−−− −−− No fault − −
0011 OC1 Overcurrent in motor cable
(I
a
> 2.25 x I
N
; Hardware
monitoring)
In the event of a short circuit. l Search for the cause of the
short circuit.
l Check the motor cable.
Capacitive charging current of the
motor cable is too high.
Use motor cable which is shorter
or of lower capacitance.
Too short acceleration or
deceleration times in proportion
to the load (C0012, C0013,
C0105).
l Increase the gain (P
component) of the Imax
controller (C0075).
l Reduce integral−action time
(integral action component) of
the Imax controller (C0076).
l Encoder error
l Tracks during encoder
feedback of the motor speed
are interchanged.
Check wiring of the encoder.
DC−injection braking at high
speeds.
l See  9.4−1
Missing mains phase. l Check the connections and the
supply cable of the device.
l Check mains voltage.
0012 OC2 Motor cable earth fault One of the motor phases has
earth contact.
l Search for cause of short
circuit.
l Check motor cable.
0013 OC3 Overload during acceleration. Too short acceleration or
deceleration times in proportion
to the load (C0012, C0013,
C0105).
l Increase the gain (P
component) of the current
controller (C0075).
l Reduce the reset time (integral
action component) of the I
max
controller (C0076).
l Increase ramp times.
l  9.4−2, "controller in clamp
operation (fault OC3)"
0015 OC5 I x t overload l Frequent and too long
acceleration with overcurrent
l Continuous overload with
I
motor
> 1.05 x I
rx.
Check drive dimensioning.
0016 OC6 I
2
xt overload l Frequent and too long
acceleration processes with
motor overcurrent.
l Permanent motor overload
with I
motor
>I
rmotor
Check drive dimensioning.
x018 OC8 I
2
xt overload advance warning l Frequent and too long
acceleration processes with
motor overcurrent.
l Permanent motor overload
with I
motor
>I
rmotor
Check drive dimensioning.
