8.6 Selection lists
8.6.1 Selection list 1: Analog output signals
Parameter Analog output signal ()
000050 AIN1−OUT
000055 AIN2−OUT
000100 DFSET−NOUT
001000 FIXED0%
001006 FIXED100%
001007 FIXED−100%
005000 MCTRL−nset2
005001 MCTRL−NACT
005002 MCTRL−MSET2
005003 MCTRL−MACT
005004 MCTRL−IACT
005005 MCTRL−DCVOLT
005006 MCTRL−VACT
005007 MCTRL−FACT
005008 MCTRL−IxT
005009 MCTRL−PHI−ACT
005010 MCTRL−M−TEMP
005015 MCTRL−BOOST
005050 NSET−NOUT
005051 NSET−RFG−I
005052 NSET−C10−C11
005100 MPOT1−OUT
005150 PCTRL1−OUT
005250 NLIM1−OUT
005500 ARIT1−OUT
005505 ARIT2−OUT
005510 ARIT3−OUT
005540 SQRT1−OUT
005550 ADD1−OUT
005555 ADD2−OUT
005600 RFG1−OUT
005610 SRFG1−OUT
005611 SRFG1−DIFF
005650 ASW1−OUT
005655 ASW2−OUT
005660 ASW3−OUT
Parameter Analog output signal ()
005700 ANEG1−OUT
005705 ANEG2−OUT
005750 FIXSET1−OUT
005800 LIM1−OUT
005850 ABS1−OUT
005900 PT1−1−OUT
005905 PT1−2−OUT
005950 DT1−1−OUT
006100 MFAIL−NOUT
006150 DB1−OUT
006200 CONV1−OUT
006205 CONV2−OUT
006210 CONV3−OUT
006215 CONV4−OUT
006230 CONVPHA1−OUT
006300 S&H1−OUT
006350 CURVE1−OUT
006400 FCNT1−OUT
010000 BRK1−M−SET
011000 DCALC1−D−OUT
011001 DCALC1−OUT
011050 PCTRL2−OUT
011100 INT1−AOUT
011105 INT2−AOUT
011150 FOLL1−OUT
015030 MCTRL−LOAD−I2XT
019500 FCODE−17
019502 FCODE−26/1
019503 FCODE−26/2
019504 FCODE−27/1
019505 FCODE−27/2
019506 FCODE−32
019507 FCODE−37
019510 FCODE−108/1
019511 FCODE−108/2
019512 FCODE−109/1
