Acceleration, deceleration, braking, stopping
Quick stop
6.10
6.10.3
6.10−4
EDSVF9383V EN 7.1−04/2012
6.10.3 Quick stop
Quick stop brakes the drive to standstill with the deceleration time set in
C0105.
ƒ DC−injection braking (GSB) has priority over quick stop.
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0105 QSP Tif 5.00 0.00 {0.01 s} 999.90 Quick stop deceleration time
l The deceleration time refers to
a speed variation of C0011 ... 0
8.2−25
8.2−40
Via digital signal:
ƒ MCTRL−QSP = HIGH.
ƒ Activating signal DCTRL−QSP. The signal can be activated via 3 OR’d
inputs:
– Control word CAN−CTRL.B3 from CAN−IN1
– Control word AIF−CTRL.B 3 from AIF−IN
– Control word C0135.B3
Via keyboard of the keypad:
For this the key must be assigned with the quick stop function (C0469 = 2):
– activates quick stop
– restarts the drive
Description
Activation
