Parameter setting
Important notes
7
7.1

7.1−1
EDSVF9383V EN 7.1−04/2012
7.1 Important notes
The controller functions can be adapted to your applications by means of
parameterisation. You can either parameterise via keypad, PC or via the
parameter channel of a bus system.
The function library contains a detailed description of the functions, the
signal flow diagrams contain all configurable signals.
The parameters for the functions are stored in numbered codes:
Æ’ Codes are marked in the text with a "C" (e.g. C0002).
Æ’ The code table provides a quick overview of all codes. The codes are
sorted according to their numbers and can be used as reference.
( 8.5−1)
A quick parameter setting is provided by the keypad XT. Moreover, it serves
as status display, error diagnosis and transfer of parameters to other drive
controllers.
Keypad XT
EMZ9371BC
Can be used with 8200 vector, 8200 motec, starttec, Drive PLC,
9300 vector, 9300 servo
Operator buttons 8
Plain text display yes
Menu structure yes
Configurable menu (user menu") yes
Predefined basic configurations yes
Non−volatile memory for parameter transfer yes
Password protection yes
Diagnosis terminal Keypad XT in handheld design, IP 20
(E82ZBBXC)
Installation in control cabinet no
Type of protection IP 20
Detailed description  7.2−1
Adapting the controller
functions to the application
Parameters and codes
Parameter setting via keypad
