Configuration
Code table
8
8.5
8.5−68
EDSVF9383V EN 4.0−03/2006
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C1583 fset high 100.0
0
0.00 {0.01 %} 199.99 Alterations by Lenze service only!
Adaptation of the motor
magnetising current set in C0095
(with V/f characteristic control:
influence limit of the boost
correction; with vector control:
influence limit of the field
precontrol)
l The output frequency is set up
to which the motor
magnetising current set in
C0095 is to have an effect.
l C1583 = 100 % ¢ half the
rated motor frequency in
C0089
6.11−5
C1751
0 {1} 65535
Inverter compensation
characteristic (WRK)
l During the motor parameter
identification, the
characteristic is calculated
from the measured motor
stator resistance and saved in
C1751/1 ... C1751/17
6.6−15
1 0
... ...
17 0
C1753
0 Data are not o. k.
Internal data are o. k.
l Motor data identification for
the inverter compensation
characteristic has been
completed successfully
1 Data are o. k.
C1754
0 Data are not o. k.
Internal data are o. k.
l Motor data identification for
the motor leakage inductance
has been completed
successfully
1 Data are o. k.
C1755
100 0 {1} 65535 Image of inverter compensation
characteristic (WRK) on the
maximum current range
