Configuration
Code table
8
8.5
8.5−67
EDSVF9383V EN 4.0−03/2006
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C1364
CFG: REF 1000 FIXED0INC Selection list 3 Input signal configuration
l Reference value
See System
Manual
(extension)
C1365
CFG: IN 1000 FIXEDPHI−0 Selection list 4 Configuration of input signal,
function block INT2
l Angle of rotation
C1366
CFG: RESET 1000 FIXED0 Selection list 2 Configuration of digital input
signal, function block INT2
l HIGH = Sets the integrator to 0
C1367 DIS: REF −2000000000 {1 inc} 2000000000 Function block INT2
l Display of the signal linked in
C13564
See System
Manual
(extension)
C1368 DIS: IN −32767 {1 rpm} 32767 Function block INT2
l Display of the signal linked in
C1365
C1369 DIS: RESET 0 1 Function block INT2
l Display of the signal linked in
C1366
C1370 FOLL max 100.0
0
0.00 {0.01 %} 199.99 Upper limit, function block FOLL1
l Upper limit of the ramp
function generator
See System
Manual
(extension)
C1371 FOLL min −100.0
0
−199.99 {0.01 %} 0.00 Lower limit, function block FOLL1
l Lower limit of the ramp
function generator
C1372 FOLL Tir 10.0 0.1 {0.1 s} 6000.0
Acceleration time T
ir
and
deceleration time T
if
of the ramp
function generator, function block
FOLL1
C1373 FOLL Tif 10.0 0.1 {0.1 s} 6000.0
C1375
Selection list 1 Configuration of analog input
signals, function block FOLL1
See System
Manual
(extension)
1 CFG: SIGN 1000 FIXED0% l Negative value: signal
characteristic at FOLL1−OUT is
opposed to the one at FOLL1−IN
l Positive value: signal
characteristic at FOLL1−OUT is
the same as at FOLL1−IN
2 CFG: IN 1000 FIXED0% If FOLL1−IN > FOLL1−REF, the ramp
function generator starts
3 CFG: REF 1000 FIXED0% Reference value
4 CFG: LOAD 1000 FIXED0% Initial value for the ramp function
generator
C1376
CFG: SET 1000 FIXED0 Selection list 2 Configuration of digital input
signal, function block FOLL1
l HIGH: initial value at
FOLL1−LOAD is accepted
C1377 −199.99 {0.01 %} 199.99
Function block FOLL1
l Display of the signals linked in
C1375
See System
Manual
(extension)
1 DIS: SIGN
2 DIS: IN
3 DIS: REF
4 DIS: LOAD
C1378 DIS: SET 0 1 Function block FOLL1
l Display of the signal linked in
C1376
