Configuration
Selection lists
Selection list 2: Digital output signals
8
8.6
8.6.2

8.6−4
EDSVF9383V EN 7.1−04/2012
Parameter
Digital output signal (
,
)
015018
MONIT−OH4
015019
MONIT−OH7
015020
MONIT−OH8
015022
MONIT−SD3
015026
MONIT−CE0
015027
MONIT−NMAX
015028
MONIT−OC5
015029
MONIT−SD5
015030
MONIT−SD6
015032
MONIT−H07
015033
MONIT−H10
015034
MONIT−H11
015040
MONIT−CE1
015041
MONIT−CE2
015042
MONIT−CE3
015043
MONIT−CE4
015044
MONIT−OC3
015045
MONIT−ID1
015046
MONIT−ID2
015047
MONIT−OC6
015048
MONIT−OC8
019500
FCODE−250
019521
FCODE−471.B0
019522
FCODE−471.B1
019523
FCODE−471.B2
019524
FCODE−471.B3
019525
FCODE−471.B4
019526
FCODE−471.B5
019527
FCODE−471.B6
019528
FCODE−471.B7
019529
FCODE−471.B8
019530
FCODE−471.B9
019531
FCODE−471.B10
019532
FCODE−471.B11
019533
FCODE−471.B12
019534
FCODE−471.B13
019535
FCODE−471.B14
019536
FCODE−471.B15
019537
FCODE−471.B16
019538
FCODE−471.B17
019539
FCODE−471.B18
019540
FCODE−471.B19
019541
FCODE−471.B20
019542
FCODE−471.B21
019543
FCODE−471.B22
019544
FCODE−471.B23
Parameter
Digital output signal (
,
)
019545
FCODE−471.B24
019546
FCODE−471.B25
019547
FCODE−471.B26
019548
FCODE−471.B27
019549
FCODE−471.B28
019550
FCODE−471.B29
019551
FCODE−471.B30
019552
FCODE−471.B31
019751
FCODE−135.B0
019752
FCODE−135.B1
019753
FCODE−135.B2
019755
FCODE−135.B4
019756
FCODE−135.B5
019757
FCODE−135.B6
019758
FCODE−135.B7
019763
FCODE−135.B12
019764
FCODE−135.B13
019765
FCODE−135.B14
019766
FCODE−135.B15
020001
CAN−CTRL.B0
020002
CAN−CTRL.B1
020003
CAN−CTRL.B2
020005
CAN−CTRL.B4
020006
CAN−CTRL.B5
020007
CAN−CTRL.B6
020008
CAN−CTRL.B7
020013
CAN−CTRL.B12
020014
CAN−CTRL.B13
020015
CAN−CTRL.B14
020016
CAN−CTRL.B15
020101
CAN−IN1.B0
020102
CAN−IN1.B1
020103
CAN−IN1.B2
020104
CAN−IN1.B3
020105
CAN−IN1.B4
020106
CAN−IN1.B5
020107
CAN−IN1.B6
020108
CAN−IN1.B7
020109
CAN−IN1.B8
020110
CAN−IN1.B9
020111
CAN−IN1.B10
020112
CAN−IN1.B11
359
361
