Lenze EVS9321-Ex System Manual

Parameter setting with the XT EMZ9371BC keypad
Commissioning example in vector control mode
6.3
6.3.2

6.3−6
EDSVF9383V EN 7.1−04/2012
NoteSwitch−on sequence
l Rated motor current (C0088)
– Lenze setting: device−dependent
Enter value for the selected motor
connection method (star/delta)!
l Rated motor frequency (C0089)
– Lenze setting: device−dependent
l Rated motor voltage (C0090)
– Lenze setting: device−dependent
Enter value for the selected motor
connection method (star/delta)!
l Motor cosj (C0091)
– Lenze setting: device−dependent
11. For protecting the motor, set the current limit
values "I
max
current" (C0022, C0023)
Guide value £ 2−fold rated motor current
Power range 0.37 ... 90 kW:
For dissipating the regenerative energy,
use a brake chopper or feedback
module, if necessary
Power range 110 ... 400 kW:
For dissipating regenerative energy, use
a brake resistor, if necessary
(see chapter "Commissioning" ®
"Motor adjustment" ® "Current limit
values")
A In motor mode and generator mode (C0022)
B Additional limitation in generator mode (C0023)
Condition: C0023 < C0022
12. If the motor temperature is monitored with a
thermal sensor KTY:
Activate the temperature feedback with C0594
(fault SD6)
Lenze setting: 3 (switched off)
A temperature feedback with KTY has a
positive effect on the vector control,
since the motor data identification
considers the temperature influence in
the motor model.
(see chapter "Commissioning" ®
"Motor adjustment")
13. Start the motor data identification "ident run"
(C0148)
(see chapter "Commissioning"
®"Adjusting the motor")
A Ensure that the controller inhibit is active
misc008
59 28
X5
}
Terminal X5/28 = LOW
B Switch on the mains
C Set C0148 = 1
D Enable controller
misc009
59 28
X5
}
Terminal X5/28 = HIGH
The identification starts:
l The segment  goes off
l "WRK run" is displayed
l The motor is energised and
"whistles"
l The motor does not rotate
E If after approx. 1 ... 2 min the segment  is active
again, inhibit the controller
misc008
59 28
X5
}
Terminal X5/28 = LOW
The identification is completed. The
following values have been detected
and entered into the codes:
l Inverter error characteristic
(C1753/xx)
l Rotor resistance "Mot Rr" (C0082)
l Stator resistance "Mot Rs" (C0084)
l Leakage inductance "Mot Lss"
(C0085)
l Stator inductance "Mot Ls" (C0092)
14. Set the operating mode "vector ctrl" (C0006)
Lenze setting: 5 (V/f characteristic control)
(see chapter "Commissioning" ®
"Operating mode" ® "Vector control")
15. Set the switching frequency "fchop" (C0018)
Lenze setting:
Power range 0.37 ... 90 kW: 6 (8/2 kHz sin)
Power range 110 ... 400 kW: 6 (4/2 kHz sin)
See chapter "Commissioning" ®
"Switching frequency of the inverter"
16. Set your type of the speed feedback system
"Feedback type" (C0025)
Lenze setting: 1 (no feedback)
See chapter "Commissioning" ®
"Setting of speed feedback"
A When using a TTL encoder:
Select the encoder used under C0025
