Lenze EVS9321-Ex System Manual

Adjusting the motor
Motor selection list
6.6
6.6.2

6.6−6
EDSVF9383V EN 7.1−04/2012
Temperature sensorMotor typeC0090
U
N
[V]
C0089
f
N
[Hz]
C0088
I
r
[A]
C0087
n
N
[rpm]
C0081
P
N
[kW]
Lenze type

440 MDXMAXM−071−12−87 MDXMAXM−071−12 0.43 2510 1.40 87 400
Asynchronous
inverter − motor
(Delta connection)
Thermal contact
441 MDXMAXM−071−32−87 MDXMAXM−071−32 0.64 2510 2.10 87 400
442 MDXMAXM−080−12−87 MDXMAXM−080−12 0.95 2510 2.80 87 400
443 MDXMAXM−080−32−87 MDXMAXM−080−32 1.30 2490 3.50 87 400
444 MDXMAXM−090−12−87 MDXMAXM−090−12 2.00 2520 4.50 87 400
445 MDXMAXM−090−32−87 MDXMAXM−090−32 2.70 2530 6.10 87 400
446 MDXMAXM−100−12−87 MDXMAXM−100−12 3.90 2510 9.70 87 400
447 MDXMAXM−100−32−87 MDXMAXM−100−32 5.40 2510 12.70 87 400
448 MDXMAXM−112−22−87 MDXMAXM−112−22 7.10 2540 14.80 87 400
449 MDXMAXM−112−32−50 MDXMAXM−112−32 5.50 1440 12.50 50 400
450 MDXMAXM−132−22−50 MDXMAXM−132−22 7.50 1460 16.80 50 400
451 MDXMAXM−132−32−50 MDXMAXM−132−32 9.20 1450 19.50 50 400
The motors listed under "motor nameplate" are not available in
Global Drive Control (GDC) and the device software.
1. Enter the corresponding value listed under C0086 into the code C0086.
2. Compare the codes for the motor data with the values in the table.
– If necessary, adapt the values in the controller to the values in the
table.
3. If necessary, optimise the dynamic behaviour of your machine via the
codes C0070 and C0071.
Information on the motor
nameplate
Motor data
Field C0086 C0022 C0081 C0084 C0085 C0087 C0088 C0089 C0090 C0091 C0070 C0071 C0075 C0076
C86 Type Imax
[A]
P
r
[kW]
R
s
[W]
Ls
[mH]
n
N
[rpm]
IN
[A]
f
r
[Hz]
U
r
[V]
cos j V
pn
T
nn
V
pi
T
ni
1006 MDXMAxx−071−12 210 1.28 0.25 39.90 157.20 1355 0.85 50 400 0.70 6 300 3.6 2
1007 MDXMAxx−071−12 250 2.25 0.47 39.90 157.20 2475 1.50 87 400 0.66 6 300 2 2
1008 MDXMAxx−071−32 211 1.73 0.37 25.03 122.60 1345 1.15 50 400 0.74 6 300 3.4 2
1009 MDXMAxx−071−32 251 3.00 0.67 25.03 122.60 2470 2.00 87 400 0.70 6 300 2.5 2
1010 MDXMAxx−080−12 212 2.40 0.55 20.69 89.00 1370 1.60 50 400 0.78 6 300 3.2 2
1011 MDXMAxx−080−12 252 3.90 1.00 20.69 89.00 2480 2.60 87 400 0.73 6 300 1.6 2
1012 MDXMAxx−080−32 213 2.85 0.75 11.69 65.20 1390 1.90 50 400 0.80 6 300 3.5 2
1013 MDXMAxx−080−32 253 4.95 1.35 11.69 65.20 2510 3.30 87 400 0.77 6 300 1.9 3
1014 MDXMAxx−090−12 214 3.90 1.10 10.01 40.20 1405 2.60 50 400 0.80 6 300 2.5 2
1015 MDXMAxx−090−12 254 6.75 2.00 10.01 40.20 2520 4.50 87 400 0.77 6 300 2 2
1016 MDXMAxx−090−32 215 5.25 1.50 5.85 28.80 1410 3.50 50 400 0.78 6 300 2 2
1017 MDXMAxx−090−32 255 9.15 2.70 5.85 28.80 2525 6.10 87 400 0.76 6 300 1 2
1018 MDXMAxx−100−12 216 7.20 2.20 2.90 20.00 1425 4.80 50 400 0.80 6 300 1 1.5
1019 MDXMAxx−100−12 256 12.45 3.90 2.90 20.00 2535 8.30 87 400 0.76 6 300 0.8 1.5
1020 MDXMAxx−100−32 217 9.75 3.00 2.10 17.00 1415 6.50 50 400 0.81 6 300 2.5 1.5
1021 MDXMAxx−100−32 257 17.10 5.40 2.10 17.00 2530 11.40 87 400 0.78 6 300 1.4 1.8
1022 MDXMAxx−112−22 218 12.45 4.00 1.50 11.00 1435 8.30 50 400 0.82 6 300 2 2
1023 MDXMAxx−112−22 258 21.45 7.10 1.50 11.00 2545 14.30 87 400 0.83 6 300 1 2
1024 MDXMAxx−132−12 219 16.50 5.50 0.86 13.00 1450 11.00 50 400 0.84 6 300 1.5 2
1025 MDXMAxx−132−12 259 28.65 9.70 0.86 13.00 2555 19.10 87 400 0.83 6 300 1.3 2
1026 MDXMAxx−132−22 220 21.90 7.50 0.80 11.00 1450 14.60 50 400 0.85 6 300 1.5 2
1027 MDXMAxx−132−22 260 38.10 13.20 0.80 11.00 2555 25.40 87 400 0.84 6 300 0.95 1.8
1028 MDXMAxx−160−22 221 31.50 11.00 0.50 7.00 1460 21.00 50 400 0.85 6 300 1.9 2.2
1029 MDXMAxx−160−22 261 54.75 19.30 0.50 7.00 2565 36.50 87 400 0.85 6 300 1 2
1030 MDXMAxx−160−32 222 41.70 15.00 0.40 5.50 1460 27.80 50 400 0.87 6 300 1.7 2.5
1031 MDXMAxx−160−32 262 72.60 26.40 0.40 5.50 2565 48.40 87 400 0.86 6 300 1 1.8
Reference list of
asynchronous motors
