Parameter setting
Parameter setting with the XT EMZ9371BC keypad
Display elements and function keys
7
7.2
7.2.3
7.2−3
EDSVF9383V EN 7.1−04/2012
%
Speed controller 1 in the limitation Drive is torque−controlled
(Only active for operation with
standard devices of the 9300
series)
&
Active fault
Acceptance of the parameters
Display Meaning Explanation
' Parameter is accepted immediately Standard device operates
immediately with the new
parameter value
SHPRG ' Parameter must be acknowledged
with (
Standard device operates with the
new parameter value after being
acknowledged
SHPRG Parameter must be acknowledged in
case of controller inhibit (
Standard device operates with the
new parameter value after the
controller is enabled again
None Display parameter Change is not possible
Active level
Display Meaning Explanation
Menu Menu level is active Select main menu and submenus
Code Code level is active Select codes and subcodes
Para Parameter level is active Change parameters in the codes or
subcodes
None Operating level is active Display operating parameters
Short text
Display Meaning Explanation
alphanumeric
al
Contents of the menus, meaning of
the codes and parameters
In the operating level display of
C0004 in % and the active fault
Number
Active level Meaning Explanation
Menu level Menu number Display is only active for operation
with standard devices of the 8200
vector or 8200 motec series
Code level Four−digit code number
Number
Active level Meaning Explanation
Menu level Submenu number Display is only active for operation
with standard devices of the 8200
vector or 8200 motec series
Code level Two−digit subcode number
Parameter value
Parameter value with unit
Cursor
In the parameter level, the digit above the cursor can be directly changed
Function keys
For description see the following table
