Configuration
Function blocks
Master frequency output (DFOUT)
8
8.2
8.2.3
8.2−9
EDSVF9383V EN 7.1−04/2012
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0540
Function 0
Function selection, function block
DFOUT
l Output signal at X10
8.2−8
0 Analog input Analog input Signal at DFOUT−AN−IN is output.
Zero track can be input externally.
1 PH diff input Phase difference
input
Signal at DFOUT−DF−IN is output.
Zero track can be input externally.
2 Not assigned
3 Not assigned
4 X10 = X9 X9 is output on
X10
The input signals are buffered
C0030 is without function
5 X10 = X8 X8 is output on
X10
C0541
CFG: AN−IN 5001 MCTRL−NACT Selection list 1 Configuration of analog input
signal, function block DFOUT
l Signal in [%] of C0011
C0542
CFG: DF−IN 1000 FIXEDPHI−0 Selection list 4 Configuration of input signal,
function block DFOUT
l Speed signal
C0544
CFG: SYN−RDY 1000 FIXED0 Selection list 2 Configuration of digital input
signal, function block DFOUT
l DFOUT−SYN−RDY = HIGH:
Generating a zero pulse
C0545 PH offset 0 0 {1 inc.} 65535 Phase offset, function block
DFOUT
l Displacing the zero pulse
generated via DFOUT−SYN−RDY
by up to 360 °
l 1 rev. = 65535 inc (360 °)
