Internal motor control with V/f characteristic control (MCTRL1)
8
8.2
8.2.6

8.2−27
EDSVF9383V EN 7.1−04/2012
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0018 fchop 6 Switching frequency of the
inverter
l General rule: The lower the
switching frequency the
– lower the power loss
– higher the noise generation
– better the concentricity
factor
l Observe derating indications
for high switching frequencies
l The max. output frequency
(f
max
) is:
– fchop = 4 kHz Þ
f
max
= 300 Hz
– fchop = 2 kHz Þ
f
max
= 150 Hz
– fchop = 1 kHz Þ
f
max
= 150 Hz
 6.9−1
1 1 kHz sin loss−optimised
2 2 kHz sin concentricity−opti
mised
3 4 kHz f_top power−optimised
4 4 kHz sin noise−optimised
6 4/2 kHz sin noise/concentricit
y−optimised with
automatic
change−over to
low switching
frequency
C0021 slipcomp à −20.00 {0.01 %} 20.00 Slip compensation
à Change of C0086, C0087 or
C0089 sets C0021 to the
calculated rated slip of the
motor
l When changing over to the
vector control mode, C0021 is
set to 0

6.11−1

8.2−25

8.2−40
C0022 Imax current à 0 {0.1 A} − I
max
limit in motor mode
à depending on C0086

6.6−14
C0023 Imax gen. à 0 {0.1 A} − I
max
limit in generator mode
à depending on C0086

6.6−14
C0036 DC brk value 0.0 0.0 {0.1 A} − Set DC braking current
à depends on the controller

8.2−25

8.2−40
C0042 DIS: QSP
Quick stop
l Display only

8.2−25

8.2−40
0 QSP inactive Quick stop is not active
1 QSP active Quick stop is active
C0050 MCTRL−NSET2 −100.00 {0.01 %} 100.00 Speed setpoint, function block
MCTRL
l Display of the speed in [%] of
C0011

8.2−25

8.2−40
C0051 MCTRL−NACT −36000 {1 rpm} 36000 Actual speed value, function block
MCTRL
l Read only

8.2−25

8.2−40
C0052 MCTRL−Umot 0 {1 V} 800 Motor voltage, function block
MCTRL
l Read only
l MCTRL−VACT = 100 % = C0090

8.2−25

8.2−40
C0053 UG−VOLTAGE 0 {1 V} 900 DC−bus voltage, function block
MCTRL
l Read only
l MCTRL−DCVOLT = 100 % =
1000 V

8.2−25

8.2−40
C0054 Imot 0.0 {0.1 A} 5000.0 Actual motor current, function
block MCTRL
l Read only
l MCTRL−IACT = 100 % = C0022

8.2−25

8.2−40
