Lenze EVS9321-Ex System Manual

Configuration
Code table
8
8.5

8.5−18
EDSVF9383V EN 4.0−03/2006
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0183 Diagnostics
Diagnostics
l Display only
l If several items or fault or
status information are to be
shown, the information with
the smallest number is
displayed

7.2−10
0 No fault
101 Initialisation
102 TRIP/fault
103 Emergency stop
104 IMP message
105 Power OFF
Function is not supported
111 Operation inhibit via C0135
112 Operation inhibit via AIF
113 Operation inhibit via CAN
121 Controller inhibited via X5/28
122 Controller inhibited internally
(DCTRL−CINH1)
123 Controller inhibited internally
(DCTRL−CINH2)
124 Controller inhibited via at the
keypad
125 Controller inhibited via AIF
126 Controller inhibited via CAN
141 Switch−on inhibit
142 Pulse inhibit 
151 Quick stop via MCTRL−QSP
152 Quick stop via  at the keypad
153 Quick stop via AIF
154 Quick stop via CAN
161 DC injection braking via terminal
162 DC injection braking via C0135
163 DC injection braking via AIF
164 DC injection braking via CAN
170 Motor parameter identification is
active
250 Warning is active (C0168)
C0190 NSET arit 0
0 OUT = C46
Arithmetic function, function
block NSET
Connects main setpoint (C0046)
and additional setpoint (C0040)
See System
Manual
(extension)
1 C46 + C49
2 C46 − C49
3 C46 * C49
4 C46 / C49
5 C46/(100 − C49)
