IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0235 damping 2 1 {1 ms} 600 Filter time of the oscillation
damping, function block MCTRL
l Filter time for the internal
signal for oscillation damping

8.2−25

8.2−40
C0236 damp limit 1.0 0.0 {0.1 Hz} 20.0 Limit value of oscillation damping,
function block MCTRL
l Limit value for the internal
signal of oscillation damping
C0241 Cmp−RFG−I=0 1.00 0.00 {0.01 %} 100.00 Speed threshold in [%] for the
digital output NSET−controller
enable−I=0, function block NSET
l The analog signals NSET−NOUT
(without arithmetic and
limiting functions) and
NSET−controller enable−I are
compared
l NSET−controller
enable−I=0 = HIGH: the
differential signal between
NSET−NOUT and
NSET−controller enable−I falls
below the value in C0241
l C0241 = 100 %: n
max
See System
Manual
(extension)
C0244 BRK1 M set 0.00 0.00 {0.01 %} 100.00 Holding torque, function block
BRK1
l C0244 = 100 % = C0057
See System
Manual
(extension)
C0250 FCODE 1 Bit 0 0 1 Free control code FCODE250
C0252 Angle offset 0 −245760000 {1 inc.} 245760000 Phase offset for master frequency
processing, function block DFSET
l Fixed phase offset for digital
frequency configuration
l 1 rev. = 65536 inc

8.2−18
C0253 Angle n−trim à −32767 {1 inc.} 32767 Speed−dependent phase trimming
for the master frequency
processing, function block DFSET
à depending on C0005, C0025,
C0490
l Change of C0005, C0025 or
C0490 resets C0253 to the
corresponding Lenze setting
l 1 rev. = 65536 inc
l Value in C0253 is reached at
15000 rpm
