Lenze EVS9321-Ex System Manual

Basic devices in the power range 110 ... 200 kW
Wiring according to EMC (CE−typical drive system)
5.4
5.4.1

5.4−2
EDSVF9383V EN 7.1−04/2012
EVF9335-EV …
EVF9338-EV
K10
L1
L2
L3
N
PE
F1…F3
PES
PES
PES PES
PES
PESPES
PES
3
7
4
63
2
62
1
7
X6
28
E1
E2
E3
E5
E4
ST1
ST2
39
A1
A3
A2
A4
59
X5
33
34
K32
K31
IN2
IN3
IN4
IN1
X11
PE
U
VW
T1 T2 BR1BR2
+UG -UG
S1
K10
K10
S2
PE
101 102 103 104
L1 L2
L3
DC 24 V
Z1
+
–
PE
PE
M
3~
M
3~
KTY
X8/5
X8/8
PE
J>
PES
PES
PES
PES
PES
PES PES
PES PES
PE
Z2
JRB
RB
RB2
T2T1
RB1PE
PE
9300VEC007
Fig. 5.4−1 Example for wiring in accordance with EMC regulations
F1 ... F3 Fuses
K10 Mains contactor
Z1 Programmable logic controller (PLC)
Z2 Brake resistor
S1 Mains contactor on
S2 Mains contactor off
+U
G
, −U
G
DC−bus connection
PES HF shield termination through large−surface connection to PE
