Device description
Leuze electronic GmbH + Co. KG BPS 348i 20
NOTICE
Standard BCBG40… bar code tapes are available in various length increments in the following
heights:
- 47mm
- 25mm
Special BCBG40… bar code tapes are available in mm height increments between 20 and
140mm.
An entry wizard is available for special bar code tapes on the Leuze website under devices
BPS300 - Accessories tab. The entry wizard provides support when entering the individual
pieces of tape data and creates a query or order form with the correct part number and type
designation.
BCBG30… barcode tape with 30mm grid
000018 000021 000024 000027 000030
1 2
30
G30Leuze G30Leuze G30Leuze G30Leuze G30Leuze
3
1 Position label with position value
2 Cut mark
3 G30 = designation in plain-text for 30mm grid
Fig.3.11: BCBG30… barcode tape with 30mm grid
NOTICE
Standard BCBG30… bar code tapes are available in various length increments in the following
heights:
- 47mm
- 25mm
Special BCBG30… bar code tapes are available in mm height increments between 20 and
140mm.
An entry wizard is available for special bar code tapes on the Leuze website under devices
BPS300 - Accessories tab. The entry wizard provides support when entering the individual
pieces of tape data and creates a query or order form with the correct part number and type
designation.
