DSS-1000 User Manual
characters, no spaces nor symbols). This name is saved only on DSS-1000 and does not
affect the settings on the camera side.
6. Enter the IP Address, HTTP Port, User Name and Password of the camera you want
to connect to. For adding cameras via RTSP protocol, you need to give the URI (Uniform
Resource Identifier)A and RTSP Port (by default 554), If you do not know the URI of the
camera, click to select from the most common manufacturers on the list. Once a
manufacturer is selected, its URI is filled up on the field. If the predefined URI does not
work, check the camera specifications for details.
7. Click Get Camera Settings. DSS-1000 connects and retrieves the camera settings. The
camera streaming properties are shown on the page however the video display is still
empty at this point.
8. Click Save. The live video appears on the display window.
105
