DSS-1000 User Manual
3.2 The Live View Page
1
11
Live view display area
2
3
4
10
5
6
7
8
9
Item
Description
Camera List
Displays the channel number and camera name of the
cameras connected to DSS-1000. Drag a channel to a
window on the Live View display area to view the
1
video stream. Or, double-click All Cameras to
automatically view all cameras on the list to the Live
View display area. See Viewing the Cameras on
page 80.
Event List
Displays connection and event notifications.
Indicates the camera has been connected.
2
Indicates the camera is disconnected.
Indicates motion is detected. The number indicates the
area where motion is detected. Motion detection
settings are done on the camera side.
PTZ Control
Displays the PTZ control panel and allows users to
pan, tilt, and zoom on the channel using the PTZ
3
control buttons, as well as adjust the PTZ settings and
adjust the focus. See 2.4 Using the PTZ Control
Panel on page 35.
Preset Point
Allows users to define preset points and set the tour of
4
PTZ camera models. See Setting Preset Points on
page 37.
78
