Lexmark X46X Series - Cover Open Sensor

4-16
7014-xxx
Cover open sensor
1. Remove the right side cover. Go to “Right side cover removal” on page 4-80.
2. Disconnect the cable from connector J11 on the controller board.
3. Use a #1 Phillips screwdriver to remove the screw (A) holding the sensor.
4. Remove the cover open sensor.
A
