4-44
7014-xxx
Manual feed solenoid removal
1. Remove the left side cover. See “Left side cover removal” on page 4-33.
2. Remove the duplex. See “Duplex removal” on page 4-19.
3. Open the front access door, and place the printer on its right side.
Note: Be careful to not mar the finish of the printer.
4. Remove the two screws (A).
A
