4-24
7014-xxx
Fan removal
1. Remove the right side cover. See “Right side cover removal” on page 4-80.
2. Disconnect the cable (A) from the engine board, and remove the two screws (B) holding the fan to the right
side frame.
3. Remove the fan.
BA
