Lexmark X46X Series - Front Door Access Cover Removal

4-34
7014-xxx
6. Depress the two tabs (C) on the underside of the MFP.
7. Lift the left cover up and pull the botom of the cover away from the MFP.
Front door access cover removal
1. Remove bumper. See “Nameplate cover removal” on page 4-63.
2. Remove the two screws (A) securing the front door access cover to the front door assembly.
C
A
