Lexmark X46X Series Service Manual

4-28
7014-xxx
Fuser removal
1. Remove the rear exit guide. See “Rear exit guide assembly with sensor and reversing solenoid
removal” on page 4-78.
2. Remove the two screws (A).
3. Partially pull the fuser forward for better access.
4. Push in on the cable connector cover (B), and remove.
