Parts Catalog 7-3
7014-xxx
Assembly 1: Covers
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
1-1 40X5827 1 1 Mid rear cover
2 40X5839 1 1 Rear door
3 40X5838 1 1 Rear cover
4 40X5820 1 1 Rear left frame assembly
5 40X5821 1 1 Rear right frame assembly
6 40X5822 1 1 Right side cover
7 40X5379 1 1 Front door cover
8 40X5359 1 1 Nameplate cover
9 40X5806 1 1 Lower AIO access assembly
10 40X5778 1 1 Front access door cover
11 40X5823 1 1 Left side cover
12 40X5614 1 1 Top cover assembly
13 40X5811 1 1 Tub cover assembly
14 40X5809 1 1 USB cable mount bracket
15 40X5834 1 1 Output bin LED lens
16 40X5835 1 1 Output bin LED
17 40X5815 2 1 Op panel support
18 40X5814 2 1 Display rotation support
NS 40X5381 1 1 Primary tray
