Parts Catalog 7-5
7014-xxx
Assembly 2: Imaging
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
1 40X7545 1 1 ADF Separator roll
2 40X5472 1 1 ADF Separator pad
3 40X5470 1 1 ADF input tray
4 40X5540 1 1 ADF cable
5 40X5824 1 1 Duplex ADF unit
6 40X5804 1 1 Flatbed cushion
7 40X5825 1 1 Flatbed module
8 40X5818 1 1 Right scanner cover
9 40X5836 1 1 Operator panel button assembly
10 40X5810 1 1 UICC Cable (Operator panel cable)
11 40X5831 1 1 Operator panel USB cable
12 40X5826 1 1 Scanner front cover
13 40X5837 1 1 Op panel display
14 40X0399 1 1 Op panel display bezel X463
14 40X0400 1 1 Op panel display bezel X464
14 40X0401 1 1 Op panel display bezel X466
15 40X5813 1 1 Kickstand support
16 40X5819 1 1 Left scanner cover
NS 40X5807 1 1 ADF maintenance kit
NS 40X7546 1 1 ADF hinge, right
NS 40X7547 1 1 ADF hinge, left
