Parts Catalog 7-9
7014-xxx
Assembly 4: Electronics 2
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
4-1 40X5829 1 1 Controller board
2 40X5816 1 1 LSU hsync extension cable
3 40X5832 1 2 Stairway cable
4 40X5833 1 1 Controller board cable
5 40X5344 1 1 Fuser assembly, 115 V
5 40X5345 1 1 Fuser assembly, 230 V
5 40X5346 1 1 Fuser assembly, 100 V
6 40X5365 1 1 Duplex and media sensor assembly
7 40X5360 1 1 Access door open sensor assembly
8 40X5392 1 1 Cooling fan (screws included)
9 40X5830 1 1 Engine board,
10 40X5385 1 1 Toner low sensor
11 40X5842 1 1 LVPS/HVPS card assembly, 110 V
11 40X5841 1 1 LVPS/HVPS card assembly, 220 V
12 40X5366 1 1 Manual input sensor assembly
13 40X5369 1 1 Manual feed solenoid
14 40X5371 1 1 MPF feed clutch
15 40X5370 1 1 Media feed (ACM) clutch
16 40X5387 1 1 LSU, (printhead)
17 40X5805 1 1 Controller board fan
NS 40X5817 1 1 LSU laser diode cable
