Parts Catalog 7-11

7014-xxx

Assembly 5: Frame

Asm-

Index

Part

number

Units/

mach

Units/

FRU

Description

5–1 40X5364 1 Transfer roll, bearings, gear, spring (CBM)

2 40X5372 1 Media exit guide assembly (redrive)

3 40X5397 1 1 Front mounts

4 40X5396 N/A

Screws, miscellaneous

TP2NCX3X6PF-Ni

TP2C-4.0+8PF-Ni

M3.0*0.5+6PF-Ni

M3.0*0.5+4PF-Ni

M3.5*0.6+6P-Ni

5 40X5380 1 1 Complete duplex assembly

6 40X5453 1 1 Media (ACM) drive assembly

7 40X5451 2 2 Paper feed, ACM tires

7 40X5440 1 2 Tray 2 paper feed tires

8 40X5358 1 1 MPF tray assembly

9 40X5383 1 1 Upper front frame assembly

10 40X5368 1 1 Manual feed clutch CBM

11 40X5367 1 1 Main drive gearbox (in motor)

12 40X5363 1 1 Duplex gear drive CBM

NS 40X5400 1 1 110 V maintenance kit

NS 40X5401 1 1 220 V maintenance kit

NS 40X5402 1 1 100 V maintenance kit

Note: Kit contains the following:

Fuser (40X5344, 40X5345, or 40X2802)

Exit guide (40X5372)

Tray 1 ACM feed tires (40X5451)

Transfer roll CBM (40X5364)
