Cooling fan removal
1. Remove the rear frame cover. See “Rear frame cover removal” on page 4-40.
2. Remove the rear cover. See “Rear cover removal” on page 4-39.
3. Disconnect the cable at the connector JFAN1 (A) on the system board.
4. Remove the two screws (B).
5. Remove the cooling fan.
A
B
