Connector locations 5-7
7526
JDX1
Duplex / MFP BDC motor drive
1 VS12_DUP_ENC_LED
2 S_DUP_MPF_ENC
3Ground
4 V24_DUP_MPF_M-
5 V24_DUP_MPF_M+
JFAN1
System fan
1Ground
2 V18_FAN_MTR
3 S_FAN_FG
4NC
JFDPCK1
Paper Feed/Waste Toner Motor
and Tray 1 Pick
1 VS12_FEED_ENC 2 V24_PICK_M+
3 S_FEED_ENC 4 V24_PICK_M-
5Ground 6Ground
7 V24_FEED_MTR- 8 S_T1PK_ENC
9 V24_FEED_MTR+ 10 VS12_5V_ENC
JFDS1
Feed thru sensor
1 VS12_FDS
2 S_FDS_FB
3Ground
JFMUSB1
Front panel USB port
1Ground
2 USB_DM1
3 USB_DP1
4NC
5Ground
JFUSER1
Belt, exit, bubble sensors
1 S_FSR_BLT2_SNS 2 GD_FSR_BLT1_RTN
3 VS_BUB_LED 4 S_FSR_BUB_SNSD
5Ground 6Ground
7 S_FSR_EXIT_SNSD 8 VS_EXIT_LED
9 S_FSR_BLT1_SNS 10 GD_FSR_BLT1_RTN
System board listing (continued)
See “System board” on page 5-2.
Connector Pin # Signal Pin # Signal
