Lightware MX9x9DVI-Plus User Manual

Standalone MX DVI-Plus family
User’s Manual
Section 8. Programmers reference Page 69 / 89
8.7.10. Delete all EDID from memory
Description: Clear all User, Emulated and Last attached Monitor’s EDIDs.
Format
Example
Command
{:CLREDID}
→
{:clredid}
Response
(E_S_C)CrLf
←
(E_S_C)CrLf
Explanation: All EDIDs are cleared expecting the factory ones.
8.8. Router initiated commands
8.8.1. Restart CPU controller
Description: The CPU controller can be restarted without unplugging power.
Format
Example (MX16x16DVI-Plus)
Command
{RST}
→
{rst}
Response
(CPU_RESET…)CrLf
(<name>●Ready!)CrLf
←
←
(CPU_RESET…)CrLf
(MX16x16DVI-Plus Ready!)
Legend: <name> is the type of the matrix
Explanation: The matrix reboots and sends a message when it is ready.
Info: The response can be seen only if the connection to the router is still alive.
8.8.2. Restart EDID controller
Description: The EDID controller can be restarted without unplugging power.
Format
Example (MX16x16DVI-Plus)
Command
{:RST}
→
{:rst}
Response
(Booting…)CrLf
(BOOT●SLOT●1●STARTED)CrLf
(SL#●1●<OB_DESC>)CrLf
(SL#●1●<OB_DESC>)CrLf
(BOOT●SLOT●1●FINISHED)CrLf
…
(BOOT●SLOT●8●STARTED)CrLf
(BOOT●SLOT●8●FINISHED)CrLf
←
←
←
←
←
…
←
←
(Booting...)CrLf
(BOOT SLOT 1 STARTED)
(SL# 1 MX16X16DVI-PLUS-OB
SCH_2.5 PCB_2.5)
(SL# 1 MX16X16DVI-PLUS-OB
SCH_2.5 PCB_2.5 )
(BOOT SLOT 1 FINISHED)
…
(BOOT SLOT 8 STARTED)
(BOOT SLOT 8 FINISHED)
Explanation (MX16x16DVI-Plus router): The router reports as if it restarted all output and
input cards.
Info: The response can be seen only if the connection to the router is still alive.
