Lightware MX9x9DVI-Plus User Manual

Standalone MX DVI-Plus family
User’s Manual
Section 8. Programmers reference Page 63 / 89
8.6.5. View Installed I/O cards’ hardware
Description: Shows the hardware name and revision of the installed cards.
Info: This router model is a compact type, so there are no separate input / output cards. Separate
card slot descriptors are listed only because of compatibility issues.
Format
Example (MX16x16DVI-Plus)
Command
{IS}
→
{is}
Response
(SL#●0● <MB_DESC>)CrLf
(SL#●1●<OB_DESC>)CrLf
(SL#●2●<OB_DESC>)CrLf
(SL#●3●<OB_DESC>)CrLf
(SL#●4●<OB_DESC>)CrLf
(SL#●5●<IB_DESC>)CrLf
(SL#●6●<IB_DESC>)CrLf
(SL#●7●<IB_DESC>)CrLf
(SL#●8●<IB_DESC>)CrLf
←
←
←
←
←
←
←
←
←
(SL# 0 MX16X16DVI-PLUS SCH_2.5
PCB_2.5)CrLf
(SL# 1 MX16x16DVI-PLUS-OB
SCH_2.5 PCB_2.5)CrLf
(SL# 2 MX16x16DVI-PLUS-OB
SCH_2.5 PCB_2.5)CrLf
(SL# 3 Empty Slot)CrLf
(SL# 4 Empty Slot)CrLf
(SL# 5 MX16x16DVI-PLUS-IB
SCH_2.5 PCB_2.5)CrLf
(SL# 6 MX16x16DVI-PLUS-IB
SCH_2.5 PCB_2.5)CrLf
(SL# 7 Empty Slot)CrLf
(SL# 4 Empty Slot)CrLf
Explanation (MX16x16DVI-Plus router): The router reports as if it has two output ad two
input cards.
8.6.6. View installed controllers’ firmware
Description: Shows the firmware revisions of the installed controllers.
Format
Example
Command
{FC}
→
{fc}
Response
(<CARD_FIRMWARE>)CrLf
←
←
(CF MX-CP FW:1.0.8 @ 0x10)CrLf
(CF MX-DVI-EDID FW:3.2.3 @
0x50)CrLf
8.6.7. View current control protocol
Description: Shows the RS-232, TCP/IP control protocol.
Format
Example
Command
{P_?}
→
{p_?}
Response
CURRENT●PROTOCOL●
=●#<x>)CrLf
←
(CURRENT PROTOCOL = #1)CrLf
Legend: <x> stands for the active protocol.
Explanation: Protocol 1 is active here.
