16 iGrowSeries 100 Installation Manual 960-0001-20
Navigation – This screen is designed to assist you in navigating about the screens and where you can find
further information in this manual.
The iPonic 600™ has a unique touch sensitive navigation design that utilizes a touch wheel and 4 navigational
touch sensitive “buttons” ( HOME, CANCEL, OK, BACK). The behaviors of the wheel and buttons are
TOUCH WHEEL
o On menu type screens, the wheel is used to rotate the selected choices. Once the desired
choice is highlighted, press OK to make the selection.
o If an alphanumeric field is highlighted, the wheel can be used to increment or decrement the
data entry.
o Note that the center of the wheel is not a button.
HOME
o Pressing HOME will bring the unit back to the Main screen. If data saving might be required,
user will be prompted for input.
CANCEL
o Pressing CANCEL in the middle on an entry will bring the user back up a level, without
making any changes.
OK
o Pressing OK will prompt the system to accept the most recent data entry.
BACK
o BACK will bring the user back up one level. User will be prompted to save data, if needed.
There are also EIGHT soft “buttons” surrounding the display. Their behaviors will be described by the
notations displayed either below or above the buttons.
