960-0001-20 iGrowSeries 100 Installation and User Manual 17
4 TOUCH navigational buttons
Graphical display.
Back light will turn off after 5 minutes. NOT A TOUCH SCREEN
Button numbers match outlet numbers
AUTO FORCE ON
FORCE OFF
SETTINGS OK TO CONFIRM
8 green output status
indicators. Will turn off after 5 minutes.
1, 2, 4, and 5 control ONE
power outlet each. 3 & 6 control TWO.








7 & 8 are for low voltage
switching only. Wire internally
(page 37)
1 TOUCH
WHEEL Use to navigate and change values
8 TOUCH
buttons Press to show the
pop up screen below: (page
