Link4 iPonic 600 - Main Status Screen Entries

18 iGrowSeries 100 Installation Manual 960-0001-20
Main Status Screen Entries
Light turn on delay timer (page 25)
CO2 mode messages:
FanCut = Shut off due to fan on Active = in CO2 maintenance
mode (page 25)
Humidify mode active (page 33)
Highlighted means
output is ON
Current CO2 level (page 25)
CO2 target level (page 25)
Grow Schedule
is ACTIVE (page
28)
Alarm indicators (page 46)
Output 7 & 8 are
INTERNAL & defaulted
to OFF (page 37)
Label showing auto
or manual
operations.
Current
temperature
Temperature
targets
(page 22)
Current
temperature stage
(page 57)
Current
humidity stage
(page 57)
Current
humidity level
(page 23)
