1.4 Separate PCBAs from Panel
Carefully break out PCBA’s from panel – be very careful to not apply excessive bending to PCBA to prevent
damage to components. (Ceramic capacitors can easily be damaged by this !!)
NOTE: DO NOT distort or stress the panel too much at any time
