LogTag TRIX-8/TRIX-16 Work Instruction Manual Revision 9.20 Page 46/53
APPENDIX 3 : COMPONENT LIST
150306 PCB Only
Component
Reference Description Part# Supplier Notes
U1
Microcontroller,
SO18
PIC16LC58B-04I/SO Microchip See programming specification
U2 (for TRIX-8)
128Kbit EEPROM, SO8
24LC128I/SO
Various
2.5V operation part required
U2 (for TRIX-16)
256Kbit EEPROM, SO8
24LC256I/SO
Various
2.5V operation part required
Q1, Q2, Q3,Q5,Q6
NPN Transistor, SOT23
BC847B
Various
Q4
PNP Transistor, SOT23
BC857B
Various
B1
550mAHr LiMg
battery, 35 deg PCB mount
leads
CR2450-****
NewSun Special order – drawing required
D1 SOT23 Diode BAS16 Various
D2
SOT23 ZENER
BZX84-C9V1
Various
D4 Green LED, 0805 GB-SM0805UYGW-TR LuckyLight
Cannot substitute different
component without test as used in
battery measurement circuit!
D5
Red LED, 0805
GB-SM0805UR0W-TR
LuckyLight
C1
10uF,6.3V POLARIZED
SOLID TANT.CAP
SIZE CSR13 CASE 'D'
20% tol
Panasonic
C2,C3 15pF, 0805 NPO Capacitor - Various
C4
470uF 4V electro cap - REC
5S series
REC 5S series Beltex Size 8 x 5
C5,C7 100nF,0805 X7R Capacitor Various
R1, R11,
R12, R24
47k 5% resistor, 0805 - Various
R2
220k 25ppm (low
Temperature Co-efficient)
0805 resistor
Must be low temp coefficient!!
R3 220k 5% 0805 resistor Various
R4 15K 5% 0805 resistor Various
R5, R18, R22,R28 270E 5% 0805 resistor Various
R6,R7,R9,
R10,R15,R17, R21
100K 5% 0805 resistor Various
R8, R25 33K 5% 0805 resistor Various
R13, R14 10K 5% 0805 resistor Various
R16 1K5 5% 0805 resistor Various
R19, R20 3K3 5% 0805 resistor Various
R23 330K 5% 0805 resistor Various
R26 1M 5% 0805 resistor Various
S1 Tact Switch
RT 100k Thermistor 104AT-2 Semitec HK supplier: Rikei
X1 32768Hz Crystal Supplier: Citizen
D-PIN, S-PIN, GPIN Interface Contacts
(23R,6.0*0.9(0.4)+3.0*3.
7 (Bi-Metal)
LightPipes LED lightpipe Lenses - LogTag
Case Top half & Bottom Half - LogTag
PCB
PCB single sided, approx 43
x 43 mm in size, 1.2mm
laminate
PCB Reference: 150306
Screws (x5)
Philips B type DIA2.0 x 6mm
length, NI Plate
Rear Label
Rear label - white polyester /
Size avery J8651 /
38.1x21.2
Front Label LogTag
