LogTag TRIX-8 - Visual Inspection

LogTag TRIX-8/TRIX-16 Work Instruction Manual Revision 9.20 Page 20/53
3. Carefully solder the legs to the pads.
Visual Inspection
Thermistor legs must not be in contact with the surface of the PCB
DO NOT apply too much heat and/or solder as
thermistor sensor can be damaged or made
inaccurate by excess soldering temperature!
