8-14
8.9 Sensorless Vector Control
Group
Display
Parameter Name
Setting
Range
Default
Unit
Function
group 2
H40
[Control mode select]
3
0 ~ 3
0
-
H30
[Motor type select]
-
0.2 ~ 22.0
-
kW
H32
[Rated
slip frequency]
-
0 ~ 10
-
Hz
H33
[Motor rated current]
-
0.5 ~ 150
-
A
H34
[Motor No Load Current]
-
0.1 ~ 20
-
A
H42
[Stator resistance (Rs)]
-
0 ~ 28
-
H44
[Leakage inductance
(L)]
-
0~300.00
-
mH
Function
group 1
F14
[Time for energizing a
motor]
-
0.0~60.0
0.1
sec
If H40 [Control mode select] is set to 3, Sensorless vector control will become active.
CAUTION
Motor parameters should be measured for high performance. It is highly recommended H41
[Auto tuning] be done prior to proceeding operation via Sensorless vector control.
Ensure that the following parameters are entered correctly for high performance in Sensorless
vector control.
H30: Select motor type connected to inverter output.
H32: Enter rated slip frequency based on motor nameplate RPM and rated frequency (See 8-8).
H33: Enter motor nameplate rated current.
H34: After removing the load, select H40 [Control mode select] to 0 {V/F control} and run the
motor at 60Hz. Enter the current displayed in Cur-[Output current] as motor no load current. If it
is difficult to remove the load from the motor shaft, enter the value either 40 to 50% of the H33
[Motor rated current] or the factory default.
In case that occur torque riffle while high speed driving, lower H34-[No load current] to 30%.
H42, H44: Enter the value of the parameter measured during H41 [Auto tuning] or the factory
default.
F14: This parameter accelerates the motor after pre-exciting the motor for the set time. The
amount of the pre-exciting current is set in H34- [Motor no load current].
Directly enter the motor nameplate value except motor rating when 0.2kW is used.
