LSIS sv-ig5a User Manual

13-7
 Conduit Kit
Conduit Kit
Model
Inverter Conduit Kit 1
SV004IG5A-2/4, SV008IG5A-2/4, SV004IG5A-1
Inverter Conduit Kit 2
SV015IG5A-2/4, SV008IG5A-1
Inverter Conduit Kit 3
SV022IG5A-2/4, SV037IG5A-2/4, SV040IG5A-2/4,
SV015IG5A-1
Inverter Conduit Kit 4
SV055IG5A-2/4, SV075IG5A-2/4
Inverter Conduit Kit 5
SV110IG5A-2/4, SV150IG5A-2/4
Inverter Conduit Kit 6
SV185IG5A-2/4, SV220IG5A-2/4
13.5 Braking resistor
Input
Voltage
Inverter capacity
[kW]
100 % braking
150% braking
[]
[W]*
[]
[W]*
200V
0.4
400
50
300
100
0.75
200
100
150
150
1.5
100
200
60
300
2.2
60
300
50
400
3.7
40
500
33
600
5.5
30
700
20
800
7.5
20
1000
15
1200
11.0
15
1400
10
2400
15.0
11
2000
8
2400
18.5
9
2400
5
3600
22.0
8
2800
5
3600
400V
0.4
1800
50
1200
100
0.75
900
100
600
150
1.5
450
200
300
300
2.2
300
300
200
400
3.7
200
500
130
600
5.5
120
700
85
1000
7.5
90
1000
60
1200
11.0
60
1400
40
2000
15.0
45
2000
30
2400
18.5
35
2400
20
3600
22.0
30
2800
20
3600
* The wattage is based on Enable duty (%ED) 5% with continuous braking time 15 sec.
