LSIS sv-ig5a - Frequency Setting

6-2
6.1 Frequency setting
1st Reference
Frequency
2nd Reference
Frequency
Mult-step
Frequency
JOG
Frequency
Final
Reference
Freq.
2nd Reference
Freq. Select
Mult-step Select
① JOG Select ① JOG_FX Select ① JOG_RX Select
1st Reference
Frequency
I17~I24
Mult-function Input
I/O Group
I17~I24
I/O Group
I17~I24
I/O Group
Mult-function Input Mult-function Input
